Control and management unit 12/24 V DC for air operated pump s. C15F - C30F with air operated discharge valve and motor operated pump s. C15B18 - C30B15 - C30B18 with electromagnetic discharge valve
| Suitable for pump | C15F, C15B18, C20F, C30F, C30B15, C30B18 |
| Voltage | 12/24 V DC |
| Power consumed | 200 |
| Inlet | 9 |
| Outlet | 5 |
| Protection rating | IP64 |
| Working temperature | -25 ÷ +60 °C |
| Packing | No. 1 - 0,005 m3 |
| Net weight | 1,2 ÷ 1,4 kg |
| Gross weight | 1,1 ÷ 1,3 kg |
